CAPACITY | 200-300 kg. |
ROTOR DIMENSIONS | 380 mm. |
ROTOR LENGTH | 1000 mm. |
ROTOR SPEED | 470 rpm |
NUMBER OF ROTOR BLADES | 6 |
NUMBER OF FIXED BLADES | 4 |
MOTOR POWER | 18,5kW |
FAN MOTOR POWER. | 5,5 kW |
HELIX MOTOR POWER | 1,5 kW |
HYDRAULIC UNITE MOTOR POWER | 1,5 kW |
PLATE MOTOR POWER | 1,5 kW |
SIEVE DIAMETER | 8 -12 mm. |
It prevents most of the dust and fine dust in the recycling of injection channels with its special rotor and blade geometry design. Mobile structure with its lockable cast wheels. Automatic feedback to the extruder chamber is possible with the blower fan/venturi discharge. Alternative chambers are available to feed the guides manually or with an automatic arm.
